Electric Articulating Boom Lifts

Gradin’s Articulating Boom Lifts, engineered to tackle your highest aerial work needs with unmatched efficiency and precision. The Boom Lifts is ideal for construction, decoration, telecommunications, advertisement placement, and airport maintenance.

This powerful and versatile lift offers superior performance, advanced safety features, and exceptional reliability, making it the top choice for professionals in various industries. Browse the specifications below to discover the impressive capabilities and benefits of the Articulating Boom Lift.

Electric Articulating Boom Lifts

Flexible｜obstacle-reaching｜multi-angle

G-V20 Electric Articulating Boom Lifts

20.5 m

230/350 kg

G-V18 Electric Articulating Boom Lifts

18.2 m

230/350 kg

G-V16 Electric Articulating Boom Lifts

15.7 m

230 kg

G-V14 Electric Articulating Boom Lifts

13.8 m

230 kg

G-V11 Electric Articulating Boom Lifts

10.52 m

200 kg

G-V09 Electric Articulating Boom Lifts

9.3 m

200 kg

Features

The product is lightweight and energy-saving, and has compact design with excellent battery life.

Σ-shaped boom with compact structure and flexible extension can realize vertical lifting and horizontal extension, and has strong obstacle-surpassing ability.

160° rotatable platform provides a larger working range, while the narrow turntable with compact layout improves work efficiency.

The platform control panel is PG and Bosch Rexroth brand, which is the same as the ground control. User-friendly design with safety factors considered ensures a reliable work performance.

International brand drag chain of the telescopic jib provides safety protection and guiding capabilities for the cables inside the booms and prolongs the service life of the cables.

Equipped with solid tires, skid-proof and explosion-proof with longer lifetime, providing a stable and labor-saving operation.

Specifications

Model	G-V20	G-V18	G-V16	G-V14	G-V11	G-V09
Max Working Height	22.5m	20.2m	17.7m	15.8m	12.5m	11.3
Max Platform Height	20.5m	18.2m	15.7m	13.8m	10.5m	9.3
Max Working Radius	11.8m	11.1m	8.9m	7.5m	6.5m	5.8m
Platform Dimension (LxWxH)	1.8×0.76×1.1m	1.8×0.76×1.1m	1.4×0.76×1.1m	1.4×0.76×1.1m	1.4×0.7×1.1m	1.4×0.7×1.1m
Machine Dimension (LxWxH)	9×2.5×2.4m	8.5×2.5×2.4m	7.9×1.9×2.0m	6.5×1.76×2.0m	5.6×1.5×2.0m	5.2×1.27×2.0m
Machine Weight	10200kg	9100kg	6630kg	5960kg	5200kg	5710kg
Load Capacity	230/350 kg	230/350kg	230kg	230kg	200kg	200kg
Driving Speed	4.5km/h	4.8km/h	5.1km/h	5.1km/h/h	4.8km/h	4.8km/h
Pump Motor	12kw	12kw	4kw	4kw	4kw	4kw
LFP Battery Power	48V/420Ah	48V/420Ah	48V/420Ah	48V/320Ah	48V/320Ah	48V/320Ah
Control Voltage	24V	24V	24V	24V	24V	24V
