26.5.2025 / 4 minute read
Автомобильные лифты наружного применения: Экономия пространства при транспортировке автомобилей на многоуровневых парковках
Обзор проекта
Project Name: Four-Cylinder Four-Column Guided Car Lift (Vertical Parking Facade Solution)
Расположение: Exterior of a Car Dealership Parking Building
Application: Vertical transportation of vehicles between multi-level parking floors, enabling fast, safe, and direct vehicle access to optimize space utilization and enhance customer experience.
Background:
Due to limited land area, the car dealership required a vertical transportation system to expand vehicle storage and display space. Traditional ramps occupied excessive space and were inefficient. The four-cylinder four-column guided lift was installed externally, connecting floors seamlessly for efficient vehicle transfer without affecting the building’s interior layout.
Основные параметры
| Параметр | Технические характеристики |
|---|---|
| Грузоподъемность | 5,000 kg (Supports SUVs, sedans, etc.) |
| Скорость подъема | 0.2–0.3 m/s (Smooth acceleration/deceleration) |
| Высота подъема | 15–25 m (Covers 4-6 floors) |
| Размер платформы | 6,000 mm (L) × 3,000 mm (W) |
| Система привода | Hydraulic Synchronous Drive (Four-cylinder linkage) |
| Guide Structure | Four Heavy-Duty Columns (Wind-resistant) |
| Система управления | Intelligent Frequency Conversion + Dual Safety Redundancy |
| Protection Rating | IP54 (Dust/waterproof for outdoor use) |
| Power Supply | 380V/50Hz (Three-phase) |
Вызов
- Space Constraints & Through-Access Requirement
- No internal installation space; required external mounting without affecting aesthetics.
- Vehicles must drive straight in/out without reversing.
- High Frequency & Heavy Load
- Daily operation exceeding 50 cycles; demanded long-term reliability.
- Heavy vehicles (e.g., SUVs) required high load capacity and platform rigidity.
- Outdoor Environment Adaptability
- Resistance to rain, temperature fluctuations, and corrosion.
- Wind loads and vibrations could compromise stability.
- Safety & User Experience
- Risk mitigation for vehicle scratches during entry/exit.
- Low noise and smooth operation for customer-facing usage.
Решения
- Structural Design
- Four-column guide rails + box-frame for wind resistance.
- Through-platform design enabled bidirectional access.
- Anti-slip steel plates + guide wheels for precise parking.
- Hydraulic & Control System
- Four-cylinder synchronization (≤3mm deviation).
- Intelligent frequency conversion reduced mechanical wear.
- Multi-layer safety (tilt detection, anti-drop clamps).
- Environmental Adaptability
- Hot-dip galvanized steel + anti-corrosion coating.
- 2° inclined platform with drainage slots.
- User Experience
- LED floor indicators + voice guidance.
- Low-noise hydraulic pump (≤65 dB).
Преимущества
- Space Efficiency: External design saved internal space; 30% faster vehicle transfer.
- Reliability & Durability: 60% lower failure rate vs. single-cylinder lifts; 6-month maintenance intervals.
- Safety & Intelligence: Real-time monitoring + anti-skid design ensured accident-free operation.
- Business Value: Streamlined pickup process boosted sales conversion.
- Scalability: Modular design allowed future expansion.
