21.5.2025 / 5 minute read
20 Synchronized Scissor Lifts at Media Complex – Zero Subsidence & Millisecond Precision
Project Overview
Client: Media Complex
Application: Level-aligned lifting system for seamless media production transitions.
Scope: 20 scissor lifts (3 models), 4 silent hydraulic stations, and intelligent control system.
Basic Parameters
| Product Name | Model | Platform Size (mm) | Load Capacity (Kg) | Stroke (mm) | Quantity (Units) |
|---|---|---|---|---|---|
| Hydraulic Lift Platform | SJG1.0 | 3000 * 1500 | 2KN/㎡ | 500 | 16 |
| Hydraulic Lift Platform | SJG0.5 | 2500 * 1000 | 2KN/㎡ | 500 | 2 |
| Hydraulic Lift Platform | SJG0.3 | 1600 * 700 | 2KN/㎡ | 500 | 2 |
| Control System | |||||
| Hydraulic Pump Station (Silent) | 4 |
The Challenge
- Synchronization: 20 lifts in 4 groups with <50ms timing error.
- Zero-subsidence: 500mm stroke + 2KN/㎡ load capacity under prolonged static conditions.
- Multi-size coordination: Platforms ranging from 1.6m to 3m requiring seamless collaboration.
Solutions
- Multi-layer sync: PLC + encoders achieve ±2mm group alignment.
- Dual stabilization: Electric struts + hydraulic locks limit subsidence to <0.5mm/72h.
- Modular design: 3 lift models + silent pump stations (≤55dB) for broadcast environments.
Advantages
- Precision: <50ms inter-group synchronization.
- Load reliability: 40-ton total capacity with dual stabilization.
- Silent operation: German-engineered pumps meet broadcast noise standards.
- Flexibility: 12 pre-programmed lifting modes for rapid scene changes.
